highly weather-resistant powder coating

This finishing process allows for vivid colours and strong visual-effects. It protects long-term against corrosion – including extreme environmental conditions – and offers excellent colour stability, gloss retention and weather resistance. For custom orders every nuance of the wideranging RAL colour chart is possible in glossy, matte, granular or brilliant shimmer.

Fade-resistant surfaces to suit every taste

With our aluminum roll shutter systems, you can always be sure of long-term value retention. That's thanks to our high-quality finishing process for slats and components. Depending on what the roll shutter systems are needed for, they are protected by hwr (highly weather-resistant) powder coating or the heroal 2-layer thick coating.

medium density foam

Tight Winding Slat with Wide Coverage Width

The Ultra-Protect has a large coverage width (1.61 inch) and narrow nominal thickness (0.33 inch), which means that it winds up very tightly and is best suited for use in small roller shutter boxes (Ø 7.25 inch barrel diameter with a curtain height of 8.25 ft). The extremely durable roll shutter slat with low weight (0.76 lb/ft²) fulfills wind load values of resistance class 3 with element widths up to 9.5 ft.

System Dimensions and Features

• coverage width: 1.6 in
• max. width|height: 11.5 ft|11.5 ft
• max. area: 75.3 ft2
• finished curtain weight: 0.8 lbs/ft2
• burglar resistance: RC 2
• optimized noise insulation: +10 dB
• hail class 4
• improvement of heat transfer
coefficient by up to 43%

Configuration Options and Design

• highly weather-resistant coating
with thick 2-layered lacquer
• available in a wide range of colours

HIGH density foam

Security Rollshutter Slat

The foam filling, strengthened with melamin resin, gives the Ultra-Secure its excellent bending strength and stability. With a coverage width of 37 mm and a nominal thickness of 9.5 mm the slat is tested and approved up to resistance class RC 2 in accordance with DIN 1627. The Ultra-Secure has also been awarded hail class 7.

System Dimensions and Features

• coverage width: 1.5 in
• max. width|height: 13.8 ft|13.1 ft
• max. area: 113.0 ft2
• finished curtain weight: 1.8 lbs/ft2
• burglar resistance: RC 2
• optimized noise insulation: +10 dB
• hail class 7
• improvement of heat transfer
coefficient by up to 41%

Configuration Options and Design

• highly weather-resistant surface
with 2-layer thick coating
• available in a wide range of colours

EXTRUDED ALUMINUM SLATS

The Ultra-Guard Shutters are specifically designed to provide an additional level of deterrence to compliment any existing security measures to meet your commercial needs.  Thick gauge, extruded aluminum slats with a 59mm slat face are available in Solid, Grid and Rectangle designs and can be combined in any formation dependent on the specified needs of the commercial application. Stainless Steel End Retention provides greater strength to enable low deflection over large widths.  Presently, these high deterrence shutters are silver with other colors available on special order.  For commercial use, with or without display applications, the Ultra-Guard Shutter is an ideal fit!

System Dimensions and Features

• Ultra-Guard solid, grid or rectangle punched 59mm wall height, clear anodized, aluminum extruded slat

• HTF-40 Secure Guide Rail features a 40mm slat channel making it more tamper resistant and a beefed up high strength aluminum wall

• Secure End Slat in 45 and 52mm widths.  Additional security measures such as keyed locks can be added to the 52mm end slat for greater peace of mind

• Anti-Push Up Mounts add still another layer of security for curtain attachments

• Somfy Motor from the world’s leading Roll Shutter motor manufacturer

Operate your rollshutters with the touch of a button. Motorized shutters offer comfort, ease and flexibility with an intuitive control system and premium design. From a control aspect, manual crank, remote controls and even smartphone apps, there’s something to suit everyone’s needs. The home control systems feature a timer option allowing you to control the home environment remotely. In addition to this, the shutters can operate in accordance with a sensor that can detect specific light intensity and room temperature. This feature maintains the desired room temperature in summer and prevents the overheating of the rooms. In winter, this feature can utilize the incoming sun rays to heat the room and also save on heating costs. Providing comfort, energy-saving features, and flexibility, heroal´s roller shutters are a great way to maximize the potential of your home.
